                            PEEK5600CF30(黑色)該材料填充30%碳纖維增強,比PEEK5600GF30有更好的機械性能(較高的彈性模量、機械強度和蠕變)和更耐磨,而且加碳纖維增強的塑料要比未增強的PEEK塑料具有3.5倍的導熱性,更快地從軸承表面散熱。
PEEK5600CF30粒子可用于注塑、擠出的方式進行生產和加工。
依托此前在PEEK行業的經驗積累,公司進軍PEEK樹脂的聚合生產,為國內PEEK零件及型材提供更多的選擇以及更強的保障,為國內PEEK的發展創造優勢條件。同時通過客戶對型材和零件的研發生產及反饋,也會促進君昊原料樹脂聚合的改進。
| 項目
 (Item)  |
測試標準或儀器 (Test Standard or Instrument)  |
單位
 (Unit)  |
PEEK5600CF30 |
| 含30%碳纖(PEEK+30%Carbon fiber) | |||
| 拉伸強度(23℃)
 Tensile strength(23℃)  |
ISO527-2/1B/50 | MPa | 250 |
| 拉伸模量(23℃)
 Tensile modulus(23℃  |
ISO527-2/1B/51 | GPa | 23.0 |
| 拉伸延伸率(23℃)
 Tensile elongation(23℃)  |
ISO527-2/1B/50 | % | 1.6 |
| 彎曲強度(23℃)
 Bending strength(23℃)  |
ISO 178 | MPa | 350 |
| 彎曲模量(23℃)
 Bending modulus(23℃)  |
ISO 178 | GPa | 18 |
| 壓縮強度(23℃)
 Compressive strength(23℃)  |
ISO 604 | MPa | 300 |
| 簡支梁沖擊強度( 無缺口)
 Charpy tched impact strength( no gap)  |
ISO 179/U | KJ/m2 | 45 |
| 懸臂梁沖擊強度(缺口)
 Lzod impact strength  |
ISO 180/A | KJ/m2 | 9 |
1、典型數值為注塑指標。如有需要可來電咨詢我司技術部索要更詳細的技術指標?。↖f you need other parameter, please contact us!)
2、該性能指標不可作為材料驗收標準。(This performance index cannot be used as acceptance criteria.)
| 項目(Item) | 測試標準或儀器
 (Test Standard or Instrument)  |
單位(Unit) | PEEK5600CF30 |
| 含30%碳纖(PEEK+30%Carbon fiber) | |||
| 熔點
 Melting point  |
DSC | ℃ | 343 |
| 熱變形溫度
 Distortion temperature  |
ISO 75-1/-2 | ℃ | 330 |
| 連續使用溫度
 Continuous using temperature  |
UL 74685 | ℃ | 260 |
| 熱膨脹系數
 coefficient of thermal expansion  |
ASTM D696 | ppm K-1 | 10 |
| 易燃性等級
 Flammable level  |
UL 94 | / | V-0 |
| 導熱系數
 Thermal conductivity  |
ISO 22007 | W/(m·K) | 0.95 |
1、典型數值為注塑指標。如有需要可來電咨詢我司技術部索要更詳細的技術指標?。↖f you need other parameter, please contact us!)
2、該性能指標不可作為材料驗收標準。(This performance index cannot be used as acceptance criteria.)
| 項目
 (Item)  |
測試標準或儀器
 (Test Standard or Instrument)  |
單位
 (Unit)  |
PEEK5600CF30 |
| 含30%碳纖(PEEK+30%Carbon fiber) | |||
| 介電強度
 Dielectric strength  |
IEC 60243-1 | KV/mm | / |
| 介電常數
 Dielectric constant  |
IEC 60250 | – | / |
| 表面電阻
 Surface Resistance  |
IEC 61340 | Ω | 105 |
|
 損耗介質 Lossy medium  |
IEC 60251 | Ω·cm | / |
1、典型數值為注塑指標。如有需要可來電咨詢我司技術部索要更詳細的技術指標!(If you need other parameter, please contact us!)
2、該性能指標不可作為材料驗收標準。(This performance index cannot be used as acceptance criteria.)
| 項目(Item) | 測試標準或儀器
 (Test Standard or Instrument)  |
單位(Unit) | PEEK5600CF30 |
| 含30%碳纖(PEEK+30%Carbon fiber) | |||
| 顏色
 Color  |
– | 黑色
 Black  |
|
| 實密度
 Density  |
ISO 1183 | g/cm3 | 1.4 |
| 吸水率 (25℃.24Hrs)
 Water Abs. (25℃.24Hrs)  |
ISO 62 | % | 0.05 |
| 成型收縮率(25-24℃)
 Mould shrinking percentage  |
平行于流動方向
 Parallel to ?flow direction  |
% | 0.3 |
| 垂直于流動方向
 Perpendicular to?flow direction  |
% | 0.8 | |
| 泊松比
 Simeom Denis Poisson  |
ISO 527-2 | 0.35 | |
| 洛氏硬度
 Rockwell hardness  |
GB/T 3398.2 | HRR | 122 |
| 摩擦系數
 Friction coefficient  |
ASTM D3702 | μ | 0.28-0.4 |
| 熔融指數
 Melt flow index  |
ISO1133 | g/10min | 3 |
1、典型數值為注塑指標。如有需要可來電咨詢我司技術部索要更詳細的技術指標?。↖f you need other parameter, please contact us!)
2、該性能指標不可作為材料驗收標準。(This performance index cannot be used as acceptance criteria.)
